Requirements input

1.2.3 Entering the desired performance requirements

In addition to specifying the hardware components, you can limit the range of tolerable message runtimes in the "Performance Requirements" filter area.

No	Operator action	System response
1.	Enter the minimum, average or maximum values required in your plant. For a description of the different measured values, please refer to chapter 2.2., a brief explanation is available via tooltip directly on the control. Example: The maximum tolerable telegram transfer time of your application is 300ms. Confirm the entry by clicking the OK button.	The system has applied the entries selected by you.
	The system has sent a query with the now active filters to the database and displayed it in the performance data table. With the selected example filter settings, the system has now found only three data records that meet all criteria.

Operator action

System response

Enter the minimum, average or maximum values required in your plant. For a description of the different measured values, please refer to chapter 2.2., a brief explanation is available via tooltip directly on the control.

Example:
The maximum tolerable telegram transfer time of your application is 300ms.

Confirm the entry by clicking the OK button.

The system has applied the entries selected by you.

The system has sent a query with the now active filters to the database and displayed it in the performance data table.

With the selected example filter settings, the system has now found only three data records that meet all criteria.
